2ton Fixed Grate Biomass Boiler Used for Production of a Soybean Oil Factory in Togo

Date:2023-11-10

Multiple processes during the edible oil production require heat source. Steam boilers are commonly used as the heat medium for direct or indirect heating. Currently, soybean oil, palm oil, and rapeseed oil occupy the position of the world's three major vegetable oils. In the transformation period of high-quality global economic development, the edible oil industry will inevitably face unlimited opportunities and challenges, and the requirements for technology and supporting facilities will become increasingly strict. It faces 3 major development pressures: low production efficiency, strict environmental policies, and fierce market competition. They must accelerate the transformation and efficiency improvement, fully utilize advanced science and technology, produce safe and healthy edible oil, and achieve synchronous improvement of production quality and efficiency to enhance the core competitiveness of edible oil enterprises. An edible oil company in Togo mainly produces soybean oil places great emphasis on energy conservation, emission reduction, and the development of circular economy in production engineering. Sitong boiler's technical team provided them with a set of  2t/h DZG series biomass steam boilers after fully understanding the customer's needs. This boiler not only effectively ensures the effectiveness of the leaching process but also is very energy-saving and environmentally friendly, and facilitates operation and maintenance in the later stage. It can provide a safe and stable heat source for the customer's soybean oil processing production line in the tedious production processes of hot air drying, suction cooling, crushing/peeling, steaming and frying.

The DZG series biomass boiler produced by Sitong boiler is a horizontal single drum vertical three passes shell water fire tube boiler, which is equipped with smooth water-cooled wall pipes on both sides of the furnace and two sets of smoke pipes arranged inside the drum. It uses a fixed grate and manual feeding way. It is also equipped with a blower and induced draft fan. The boiler adopts a large drum design and reinforced heat transfer threaded smoke pipes with a large number of smoke pipes, large multi return heating area, fast temperature rise and pressure rise, and good heat transfer effect. The boiler has the characteristics of sufficient steam, hight thermal efficiency ,low usage cost, and customization. And the inner liner of the boiler is made of boiler specific steel plates with automatic welding of the welds and non-destructive testing. The drum corresponds to water pressure testing and has a long service life. The boiler has an independent electric control system operation that can automatically feed and replenish water. It also has multiple safety guarantees such as high and low water level alarm, low water level protection, and overpressure protection. It has a high degree of automation and can save a lot of labor costs. The picture shows the delivery site of the boiler:
